CALB L173F314A 314Ah prismatic LiFePO4 Battery solves critical industry challenges:
⚡ 6000 Deep Cycles @25°C – 2× industry average lifespan
❄️ -30℃ Arctic Operation – Full functionality in extreme cold
🔋 394Wh/L Energy Density – 18% higher than standard LFP cells
Certified Specifications (Per CALB Spec A01)
| Parameter | Value | Advantage |
|---|---|---|
| Nominal Capacity | 314Ah ±1% | 1004Wh energy per cell |
| Continuous Power | 502.4W (0.5P) | Sustains high-load equipment |
| Cycle Life | ≥6000 cycles | ≤$0.008/cycle cost |
| AC Internal Resistance | ≤0.35mΩ | Minimizes energy loss |
| Volume Energy Density | 394Wh/L | Compact system design |
| Safety Certification | EUCAR Level 2 | Passes nail/crush/130°C tests |
Engineering Superiority
✅ Vibration-Resistant – Withstands 8h XYZ-axis vibration (per GB/T)
✅ 180-Day Storage – ≤3% capacity loss at 25℃
✅ 800kgf Compression – Reinforced aluminum casing
Application Scenarios
• Grid-Scale ESS: 1MW/2MWh containerized systems
• Industrial EVs: Mining trucks & port logistics vehicles
• Telecom Backup: 48V tower power stations
ACT NOW！！！
Contact us immediately to obtain the free specification sheet and bulk quotation of CALB 314Ah LFP Battery
