Our cutting-edge lithium-ion battery series combines semi-solid technology and ultra-high energy density to deliver unmatched performance for demanding applications. Designed with advanced 811/Ni-rich cathode materials and silicon-enhanced graphite anodes, these batteries prioritize safety, longevity, and power efficiency. Below is a detailed overview of our premium models:
Key Features
✅ Semi-Solid Technology: Enhanced electrolyte stability for safer operation and reduced risk of thermal runaway.
✅ High Energy Density: Up to 270 Wh/kg for compact, lightweight designs.
✅ High Nickel/Silicon Chemistry: Optimizes capacity and cycle life.
✅ Wide Temperature Range: Operates reliably from -20°C to 60°C.
✅ Rapid Charging/Discharging: Supports high continuous currents for fast power delivery.
Product Specifications Table of Semi-Solid State Battery
| Specifications | 16000mAh | 22000mAh | 27000mAh | 30000mAh | 31000mAh |
|---|---|---|---|---|---|
| Nominal Voltage (V) | 3.7 | 3.7 | 3.7 | 3.7 | 3.6 |
| Chemistry | NCM811/Graphite+Si | NCM811/Graphite+Si | NCM811/Graphite+Si | NCM811/Graphite+Si | Medium-Ni/Graphite+Si |
| Capacity (mAh) | 16,000 | 22,000 | 27,000 | 30,000 | 31,000 |
| Dimensions (mm) | 172×74×7.7 | 172×74×10.6 | 187×87×9.8 | 187×87×10.8 | 187×87×10.8 |
| Weight (g) | 226 | 299 | 363 | 407 | 418 |
| Energy Density (Wh/kg) | 270 | 270 | 270 | 270 | 270 |
| Max Charge Current (A) | 32 | 44 | 54 | 60 | 31 |
| Max Discharge Current (A) | 80 | 110 | 135 | 150 | 31 |
| Cycle Life | 800 cycles | 800 cycles | 800 cycles | 800 cycles | 1000 cycles |
| Standards Compliance | GB38031-2020 | GB38031-2020 | GB38031-2020 | GB38031-2020 | GB/T31485-2015 |
Technology Highlights
- Semi-Solid Design:
- Utilizes a hybrid electrolyte system to minimize leakage risks and enhance thermal stability.
- Ideal for high-stress environments such as electric vehicles (EVs) and industrial equipment.
- High-Density Chemistry:
- NCM811 Cathode: Nickel-rich cathode (80% Ni, 10% Co, 10% Mn) maximizes energy output.
- Silicon-Doped Anode: Graphite infused with silicon increases lithium-ion storage capacity by up to 20%.
- Superior Performance:
- Ultra-Fast Charging: Supports up to 150A continuous discharge (30000mAh model).
- Extended Cycle Life: The 31000mAh variant achieves 1000 cycles at 0.5C/0.5C, ideal for long-term applications.
Applications
- Electric Vehicles: High power output for EVs, e-bikes, and marine propulsion.
- Energy Storage Systems (ESS): Solar storage, UPS, and grid stabilization.
- Industrial Equipment: Robotics, medical devices, and telecom infrastructure.
Why Choose Our Semi-Solid State Battery?
- Safety First: Compliant with GB38031-2020 and GB/T31485-2015 standards for rigorous safety testing.
- Custom Solutions: Tailored BMS integration and SOC adjustments available.
- Global Support: Fast delivery (15–30 days) and dedicated technical assistance.
Contact Us Today to explore how our high-density, semi-solid batteries can power your innovations!
Note: Specifications may vary slightly based on customization. All products undergo strict quality control.
Visual Table for Web Display (Image-Friendly Format)
| Model | Capacity | Key Technology | Energy Density | Max Discharge | Cycle Life |
|---|---|---|---|---|---|
| 16000mAh | 16Ah | NCM811/Si-Graphite | 270 Wh/kg | 80A | 800 cycles |
| 22000mAh | 22Ah | NCM811/Si-Graphite | 270 Wh/kg | 110A | 800 cycles |
| 27000mAh | 27Ah | NCM811/Si-Graphite | 270 Wh/kg | 135A | 800 cycles |
| 30000mAh | 30Ah | NCM811/Si-Graphite | 270 Wh/kg | 150A | 800 cycles |
| 31000mAh | 31Ah | Medium-Ni/Si-Graphite | 270 Wh/kg | 31A | 1000 cycles |
